LOADER MODEL

2660L

Standard Bucket Size [in]

72

Maximum Lift Height [in]

115.4

Dig Depth [in]

5.2

Lift Capacity to Full Height at Pivot Pin [lbs]

3122

Breakout Force [lbs]

5225

Shipping Weight [lbs}

1270

ENGINE

Type

Four-stroke, TurboCharged, Direct Injection, Water Cooled Diesel Engine

Engine HP {kW} @ RPM

60 (44.5) @ 2300

Displacement [in³ (cc)]

161.7 (2650)

Number of Cylinders

3

Fuel Tank [gal (L)]

16 (60.6)

DRIVE TRAIN

Transmission

HST - 3 Ranges

Number of Speeds

Infinite

Clutch

Damper

Brakes

Wet Disc Brake, Mechanical

PTO

Type

Independent

Rear PTO RPM

540 @ 2300

Mid PTO RPM

2000 @ 2500

PTO HP (kW)

46.3 (34.5)

HYDRAULICS

Type

Open Center

Implement Pump Output [gpm (L/min)]

11.8 (44.7)

Maximum Total Flow [gpm (L/min)]

16.7 (63.2)

3-Point Hitch

CAT 1 w/Telescoping Stabilizers & Flex Links

Lift Capacity [lb (kg)]

3314 (1503)

ELECTRICAL

Battery

12 V, 925 CCA

Alternator

12 V, 90 A

DIMENSIONS

Overall Length [in (mm)]

138.8 (3525)

Overall Width [in (mm)]

71.1 (1805)

Overall Height [in (mm)]

102 (2590)

Wheelbase [in (mm)]

73.7 (1871)

Minimum Ground Clearance [in (mm)]

14.5 (370)

Turning Radius [ft (m)]

N/A

Weight [lb (kg)]

4145 (1884)

WHEELS & TIRES

AG [Front/Rear]

9.5 x 16 6PR / 14.9 x 24 6PR

IND [Front/Rear]

12 x 16.5 / 16.9 x 24

TURF [Front/Rear]

N/A
