LOADER MODEL

2638L

Standard Bucket Size [in]

66

Maximum Lift Height [in]

101.4

Dig Depth [in]

4.5

Lift Capacity to Full Height at Pivot Pin [lbs]

1634

Breakout Force [lbs]

2696

Shipping Weight [lbs}

985

BACKHOE MODEL

Standard Bucket Size [in]

16

Maximum Dig Depth [in]

95

Dig Depth 2' Flat Bottom [in]

93.5

Dig Force Bucket [lbs]

3439

Dig Force Dipper [lbs]

2214

Shipping Weight

1250

ENGINE

Type

Four-stroke, Natually Aspirated, Direct Injection, Water Cooled Diesel Engine

Engine HP {kW} @ RPM

37.4 (27.5) @ 2400

Displacement [in³ (cc)]

166.7 (2732)

Number of Cylinders

4

Fuel Tank [gal (L)]

9 (34)

DRIVE TRAIN

Transmission

HST - 3 Ranges

Number of Speeds

Infinite

Clutch

Damper

Brakes

Wet Disc Brake, Mechanical

PTO

Type

Independent

Rear PTO RPM

540 @ 2400

Mid PTO RPM

2000 @ 2500

PTO HP (kW)

31 (23.2)

HYDRAULICS

Type

Open Center

Implement Pump Output [gpm (L/min)]

7.5 (28.7)

Maximum Total Flow [gpm (L/min)]

11.7 (44.3)

3-Point Hitch

CAT 1

Lift Capacity [lb (kg)]

2646 (1200)

ELECTRICAL

Battery

12 V, 800 CCA

Alternator

12 V, 90 A

DIMENSIONS

Overall Length [in (mm)]

119.3 (3030)

Overall Width [in (mm)]

63.2 (1605)

Overall Height [in (mm)]

94.4 (2400)

Wheelbase [in (mm)]

67.7 (1719)

Minimum Ground Clearance [in (mm)]

14.5 (370)

Turning Radius [ft (m)]

N/A

Weight [lb (kg)]

3130 (1420)

WHEELS & TIRES

AG [Front/Rear]

7-16 6PR / 11.2-24 4PR

IND [Front/Rear]

10-16.5 / 43 x 16-20

TURF [Front/Rear]

N/A
