LOADER MODEL

Standard Bucket Size [in]

48

Maximum Lift Height [in]

71.3

Dig Depth [in]

5.3

Lift Capacity to Full Height at Pivot Pin [lbs]

617

Breakout Force [lbs]

1235

Shipping Weight [lbs}

419

BACKHOE MODEL

Standard Bucket Size [in]

12

Maximum Dip Depth [in]

71.5

Dig Depth 2' Flat Bottom [in]

63

Dig Force Bucket [lbs]

2050

Dig Force Dipper [lbs]

1256

Shipping Weight [lbs]

606

ENGINE

Type

Four-stroke, Naturally Aspirated, Indirect Injection, Water Cooled Diesel Engine, Complies with US TIER-4 Final Norms

Engine HP {kW} @ RPM

19.4 (14.5) @ 3000

Displacement [in3 (cc)]

60.6 (993)

Number of Cylinders

3

Fuel Tank [gal (L)]

6.6 (25)

DRIVE TRAIN

Transmission

HST - 2 Ranges

Number of Speeds

Infinite

Clutch

Dry-Single

Brakes

Wet Disc

PTO

Type

Independent

Rear PTO RPM

540 @ 2942

Mid PTO RPM

2500 @ 2958

PTO HP (kW)

14.2 (10.6)

HYDRAULICS

Type

Open Center

Implement Pump Output [gpm (L/min)]

4.1 (15.5)

Maximum Total Flow [gpm (L/min)]

6.2 (23.4)

3-Point Hitch

CAT I Narrow with Check Chains

Lift Capacity [lb (kg)]

680 (309)

ELECTRICAL

Battery

12 V, 450 CCA

Alternator

12 V, 45 A

DIMENSIONS

Overall Length [in (mm)]

94.2 (2392)

Overall Width [in (mm)]

44.5 (1130)

Overall Height [in (mm)]

86.6 (2299)

Wheelbase [in (mm)]

53.1 (1348)

Minimum Ground Clearance [in (mm)]

8.3  (210)

Turning Radius [ft (m)]

7.2 (2.1)

Weight [lb (kg)]

1499 (679.9)

WHEELS & TIRES

AG [Front/Rear]

18 x 8.5-10 / 26 x 12-12

IND [Front/Rear]

18 x 8.5-10 / 26 x 12-12

TURF [Front/Rear]

18 x 8.5-10 / 26 x 12-12
