DIMENSIONS & CAPABILITIES

 Wheelbase

 96"

 Base Curb Weight

 3035 lbs

 Length

 148" (156" w/ spare tire)

 Width

 60" - 62"

 Height

 75"

 Ground Clearance

 9"

 Fuel Capacity

 12 gallons

 Rear Payload Capacity

 349 lbs

 GVWR

 3750 lbs

 Towing Capacity

 3490 lbs

 Person Capacity

 2

 CHASSIS & SUSPENSION

 Chassis Type

 Boxed Steel Frame

 Front Suspension

 Rigid Leaf Spring w/Stabilizer Bar

 Rear Suspension

 Leaf Spring w/Shock Absorbers

 Shock Absorbers

 Double Acting Hydraulic

 PERFORMANCE

 Max Speed

 55 MPH

 Max Towing Speed

 15 MPH

 Max Flat Towing Speed

 55 MPH

 DRIVETRAIN

 Transmission

 5-speed manual or 6-speed auto

 Transfer Case

 2-speed manual

 Driveline

 2WD / 4WD

 Full/Semi Floating Rear Acle

 5.38:1

 BRAKES

 Dual Hydraulic Vac Assist

 Standard

 Parking Brake

 Standard

 Front Brakes

 11" Disc

 Rear Brakes

 11" Disc

 FEATURES

 Steering

 Hydraulic Power

 Instrumentation

 Single Gauge

 Lighting / Headlights

 Halogen

 Battery

 72 Ah / 12 V

 Alternator

 45 to 90 Amps

 Power Port

 12 V Standard

 Storage

 2 seat boxes

 Seating

 2

 Tires

 235

 Wheels / Steel

 16" - 5 x 5.5 lug

 Wheels / Aluminum (Optional)

 16" - 5 x 5.5 lug

 ENGINE

 Type

 Turbo Diesel m2DiCR

 Cylinders

 4 - 4 Stroke Compression Ignition

 Displacement

 2.5 L

 Bore & Stroke

 88.9 x 101.6 mm

 Power

 62 HP @ 3200 rpm

 Torque

 144 ft lbs @ 1400 - 2200 rpm

 Compression Ratio

 18.6 : 1

 Cooling System

 Liquid

 Fuel System

 Direct Injection
